Industrial Belt EP 500 For Stone Crusher Manufacturers' Best Durable Rubber Polyester PU Plastic Nylon-Stone Powder Conveyor

Application

Heat Resistance / Fire Resistance

Abrasion Resistance / Anti-static

Cold Resistance / Oil Resistance

Products Description

Conveyor belts are designed to the highest standards, to transport all types of bulk material, including mining, stone and earth handling, building industries, recycling, steel processing, wood, paper and pulp.

Properties

Resistant to impact
High strength
Low elongation
High resistant to abrasion
Suitable for long distance, large loading capacity and high speed transportation

Manufacturing Standards

GB/T 7984 DIN 22102 JIS K 6322 AS 1332-2000 SANS 1173:2005 BS 490

Conveyor Belt Properties

Rubber conveyor belts have the following properties depending on the environment in which they are used:

Cold Resistance Heat Resistance Anti-static Fire Resistance Oil Resistance Abrasion Resistance

Specification

Parameter	Standard Metric Specifications	Imperial/Alternative Specifications
Cover Rubber Grade	8MPA, 10MPA, 12MPA, 15MPA, 18MPA, 20MPA, 24MPA, 26MPA	DIN-X, Y, W RMA-1, RMA-2 N17, M24
Belt Width (mm)	500, 600, 650, 700, 800, 1000, 1200, 1400, 1500, 1800, 2000, 2200, 2500, 3000	18", 20", 24", 30", 36", 40", 42", 48", 60", 72", 78", 86", 94"
Tensile Strength	EP315/3, EP400/3, EP500/3, EP600/3, EP400/4, EP500/4, EP600/4, EP500/5, EP1000/5, EP1250/5, EP600/6, EP1200/6	330PIW, 440PIW
Top + Bottom Thickness	3+1.5, 4+2, 4+1.5, 4+3, 5+1.5	3/16"+1/16", 1/4"+1/16"
Belt Thickness	3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 12mm, 15mm, 20mm, 25mm
Belt Length	10m, 20m, 50m, 100m, 200m, 250m, 300m, 500m
Belt Edge Type	moulded (sealed) edge or cut edge

Cooperative Partner

Quality Control

FAQ

Q1. What's the order process?

1) Inquiry: Provide us all clear requirements (total quantity and package details).
2) Quotation: Official quotation from our professional team with all clear specifications.
3) Marking Sample: Confirm all quotation details and the final sample.
4) Production: Mass production.
5) Shipping: By sea or by air.

Q2. Are you a manufacturer?

Yes, we mainly produce rubber conveyor belts and rubber V belts over 20 years.

Q3. What about the lead time?

1) 4-7 days for sample.
2) 15-30 days for mass production. If urgent, we have a green channel available.

Q4. How to pay?

1) T/T or L/C through bank account.
2) Select Alibaba Trade Assurance Service.

Q5. How do you ship the products?

By Sea, By Air, By courier, TNT, DHL, Fedex, UPS, etc. It is up to you.

Q6. Can the belt edge types be selected?

Yes, you can choose between a moulded (sealed) edge or a cut edge according to your requirements.
